What You Will Master:
Hybrid Production: Learn how to develop a single model with components optimized for different manufacturing methods (3D printing and laser cutting).
Advanced Sketching: Gain hands-on experience with the Fit Point Spline tool to create smooth, organic, and personal abstract designs.
Precision Engineering: Design a perfectly toleranced 8.2mm central hole to accommodate a standard short spindle clock mechanism.
Efficiency Tools: Master the Extend, Trim, and Offset commands to refine complex geometries quickly
Patterns & Logic: Use the Circular Pattern tool to accurately place time notches across a 180-degree partial distribution.
Multi-Format Exporting: Learn the professional workflow for exporting DXF files for laser cutting and STL files for 3D printing.
Tutorial Specifications:
Skill Level: 2 / 10 (Beginner Friendly).
Software: Autodesk Fusion.
Project Outcome: A personalized, fully functional clock with a professional abstract aesthetic.
What’s Included: A comprehensive step-by-step guide with annotated screenshots and technical learning checks to verify your skills.
Show off your skills and create a piece of functional art for your wall.
